Quick Details

Application: PVC sheet

Plastic Processed: rigid PVC, soft PVC, transparent PVC

Screw Design: Double-screw

Automatic Grade: Automatic

Place of Origin: Jiangsu, China (Mainland)

Brand Name: sansu

Voltage: 380V 50HZ,415V/50HZ, 440V/60HZ, 220V/60HZ

Dimension(L*W*H):68*12*6m

Weight:2-15T

Certification: CE ISO BV

After-sales Service Provided: Engineers available to service machinery overseas

Total installed capacity:80 KW

Warranty:12 Months after installation in customer’s factory

Linear speed: 3-15m/min(adjustable)

Extruder capacity: 250-350kg/h

Roller length:2300mm

Steel roller diameter:400

Packaging & Delivery

Packaging Details Film cover

Delivery Time 40 days upon receiving deposit

1. Double screw extruder

2. T Die head

4. Three-roller calender

5. Roller tem-controlling device

6. Cooling shelf

7. haul off machine

8. Cutting device

10. Winding device

11. Electrical Controlling system

Technical Parameter

Working Process

The unit mainly PVC, CaCO3 and other additives as raw material, after extruder and die cast By a three roller calender machine , cooling bracket setting ,A/B/A three-layer coextrusion waterproofing membrane .B layer can be different according  to user requirements for product quality adjustment, in order to reduce the cost of products(such as a layer of polypropylene fabric ,polyester fabric ,B layer material ) and B layer can also be based require the use of different materials to meet the diverse requirement of user of the products to meet market demand . This production line can produce PVC/TPO multilayer waterproof membrane, it consists twin screw extruder, die , three roller stack and auxiliary  equipments, it can produce the membrane from 0.5mm to 4mm ,monolayer, multi-layer and laminated with non-woven fabric.

Finished Products Characteristics

This is a unique new type of membrane production system and unique systems designed and installed so that our products have the following characteristics:

1.Excellent solderability

2.Softness and flexibility

3.Highly dimensional stability

4.High temperature resistance, anti-UV ability to Non-toxic

5.A wide range of chemical resistance to corrosion

Q3:How about the delivery time?

A :Delivery time about 40days after your deposit or L/C at sight.

Q4:What kind of payment do you support?

A :T/T, L/C and Paypal are accepted.

Q5:What's your main market?

A :Our products are exported to Southeast Asia,The middle East,West Europe,Africa,Australia

and etc.

Q6:Can we visit your factory to inspect the goods for the order?

A :Welcome to visit our factory to inspect the quality. We sincerely hope to establish a cooperation relationship with you.
